2PCS UAV RTK GNSS handheld Receiver helical spiral GNSS antenna RTK GNSS GPS antenna GLONASS GALILEO BEIDOU ZED-F9P SMA-J TOP508
  • 2PCS UAV RTK GNSS handheld Receiver helical spiral GNSS antenna RTK GNSS GPS antenna GLONASS GALILEO BEIDOU ZED-F9P SMA-J TOP508
  • 2PCS UAV RTK GNSS handheld Receiver helical spiral GNSS antenna RTK GNSS GPS antenna GLONASS GALILEO BEIDOU ZED-F9P SMA-J TOP508
  • 2PCS UAV RTK GNSS handheld Receiver helical spiral GNSS antenna RTK GNSS GPS antenna GLONASS GALILEO BEIDOU ZED-F9P SMA-J TOP508

2PCS UAV RTK GNSS handheld Receiver helical spiral GNSS antenna RTK GNSS GPS antenna GLONASS GALILEO BEIDOU ZED-F9P SMA-J TOP508

  • $236
    10-19
    Pieces
  • $224.2
    20-39
    Pieces
  • $212.4
    40-99
    Pieces
  • $188.8
    ≥100
    Pieces
10 Piece/Pieces (5 batch) (Min. Order)
1 batch = 2 Piece/Pieces
Quantity:

0 Piece,Product Price: US $ 0

  • Lead Time:/ days
  • Shipping time:/ days
  • Product Description
Overview
Product Attributes
Brand Name:
TOPGNSS
Model Name:
TOP508
GPS type:
Receiver & Antenna
Connector type:
SMA
Frequency Range:
GPS L1/L2, GLONASS G1/G2 ,BDS:B1,B2,B3.GALILEO E1,Eb5
weight:
18g
Name:
High precision UAV GNSS antenna
LNA low noise amplification gain:
35DB
Brand Name:
TOPGNSS
Packaging & Delivery
Selling Units:
Piece/Pieces
Single package size:
40cm*30cm*20cm
Single gross weight:
1kg
Lead Time :
Quantity(Piece/Pieces) 1 ~ 2000>2000
Est. Time(days) 7To be negotiated

If you finish the payment today, your order will ship out within the delivery date.

New product promotion

The price limits the sale of 100PCS

NEW 3-12V drone UAV RTK handheld Receiver helical spiral GNSS antenna GPS BEIDOU GLONASS GALILEO,ZED-F9P,SMA-J, TOP508


Features:
Four-walled spiral Design
small volume
Light weight
Easy to install
High precision





Model:TOP508

  excellent omnidirectional radiation characteristics. Compared with the traditional microstrip antenna, the antenna has four arm spiral structure. It has better low elevation gain and wide-angle circular polarization characteristics, and can receive more low elevation satellite signals.

 The antenna has the characteristics of small volume, high positioning precision and light weight, and can meet the needs of users effectively.
  Characteristic : quality is light. The total weight of the antenna is less than 30g, which is especially suitable for equipment such as unmanned aerial vehicle (UAV), hand held machine, wearable equipment and so on. It can greatly reduce the load burden.
  easy installation. The antenna is fed and transmitted by a standard SMA joint, and the antenna joint is connected with the signal connector of the terminal device to fix the antenna without additional installation holes.


GNSS TOP508 antenna with ZED-F9P GNSS module signal receiving performance reference map (for reference)



UAV RTK GNSS Antenna TOP1508 Test reception performance



Shaded window test results:



The design of topgnss TOP508 satellite multi frequency active helical antenna and multi arm spiral technology, support L1 and L2 dual band satellite signal receiving II, GPS, GLONASS and Beidou Galileo system to meet the measurement needs of current multi system compatibility and high precision, for handheld GNSS positioning equipment, UAV, UAV navigation and positioning applications and other high the accuracy of the.


Technical characteristics
To ensure the performance of right-hand circular polarization and phase center in multi arm spiral technology, reduce the impact of measurement error;
An antenna unit with air dielectric, high gain and low gain rolloff characteristics in low elevation satellite signal receiving effect, to ensure collection in some serious occlusion situations of normal satellite;
(1) light quality. The total weight of the antenna is not more than 20g, especially for equipment such as unmanned aerial vehicle (UAV), handset, wearable equipment and so on. It can greatly reduce the load burden.
(2) excellent omnidirectional radiation characteristics.
The antenna has a spiral structure of four arms. It has good low elevation angle gain and wide-angle circular polarization, and can receive more low elevation satellite signals.


 High precision measurement of GNSS antenna

Support: GPS,GLONASS,BEI DOU,GALILEO
GNSS system.

Features:
 Integrated BD B1 & B2 & B3 and GPS L1 & L2 and GLONASS G1 & G2 GALILEO system seven-band measurement antenna, can be widely used in geodesy, bridge construction, marine survey, underwater terrain measurement and other occasions. The antenna uses multi-feed point design to ensure that the antenna phase center and geometric center coincidence, improve the accuracy of measurement. Built-in low-noise amplifier module, the use of pre-and multi-stage filter filter interference signal to ensure that the normal work in harsh electromagnetic environment. Small size, light weight.


antenna size structure (unit: mm)





Packing list:

Included:2 PCS GNSS antenna.

       STOTON GNSS Antennas more new specifications to choose from, can provide OEM / ODM services. If you have special needs, please contact us, we will provide you with professional skills and services!
